GORBEL FALL PROTECTION

We are proud to offer the Gorbel Tether Track™ Fall Protection Systems utilizing rigid rail for fall arrest applications.

A Fall Arrest System is an active means of protecting workers from injury due to falls. A complete personal fall arrest system includes an anchor, a body harness and a connector such as a shock-absorbing fall arrest lanyard or self-retracting lanyard (SRL).

Unlike wire rope systems, Gorbel Tether Track™ Fall Arrest systems deliver shorter free fall distances, reduced risk of secondary fall injuries and an uninterrupted experience for a second worker in the event of a fall.

Using a Gorbel Tether Track™ Rigid Rail Fall Arrest System as your anchor provides workers with a high degree of mobility and freedom, while preventing falls to lower levels. Gorbel Tether Track™ Rigid Rail Fall Arrest Systems provide a reliable and cost-effective solution for reducing the risk of injury in elevated work environments. Available in various configurations, including multiple track profiles and support center distances, fall protection can be easily customized to fit every budget and application, and are designed by qualified engineers to meet OSHA standards.

Gorbel Tether Track™ Fall Arrest Systems Bridge System

Consists of two runways and a traveling bridge for maximum coverage within a rectangular work area
Lightweight aluminum bridge follows the worker, remaining directly overhead
Available in ceiling mounted or free standing designs
Plain or trussed track runways based on support center requirements
Unlimited runway lengths, with up to 18’ bridge spans
Systems are designed for workers up to 310 lbs. with tools when used with 900LB Maximum Arresting Force (MAF) energy absorbing lanyards, properly rated full-body harnesses and a connecting device
Multiple bridges can support several workers when properly zoned

Ceiling—Mounted Monorail System

Provides mobility along a single axis for applications when workers need to travel in a straight line
Curved track sections available
Variety of hanger options available to accommodate various building structures
Unlimited monorail lengths with up to 50’ between supports (dual trussed track only)
Systems are designed for workers up to 310lbs with tools when used with 900LB Maximum Arresting Force (MAF) energy absorbing lanyards, properly rated full-body harnesses and connecting device
Track can accommodate single or multiple workers, dual bypassing track allows workers to safely pass each other without disconnecting

Fold—Away System

Provides mobility along a single axis for applications when workers need to travel in a straight line
Curved track sections available
Variety of hanger options available to accommodate various building structures
Unlimited monorail lengths with up to 50’ between supports (dual trussed track only)
Systems are designed for workers up to 310lbs with tools when used with 900LB Maximum Arresting Force (MAF) energy absorbing lanyards, properly rated full-body harnesses and connecting device
Track can accommodate single or multiple workers, dual bypassing track allows workers to safely pass each other without disconnecting

Free‐Standing Monorail System

Free-standing support when structure is inadequate for ceiling mounted applications
Available in free-standing cantilevered or goal post designs. Special finishes available
Cantilevered for fewer support columns. Accommodates headroom constraints
Goal Post design can be bolted directly into concrete floor. No costly foundations!
Standard support centers from 16’ to 35’, and up to 50’ custom designed (dual trussed track only)
Systems designed for workers up to 310lbs with tools when used with 900LB Maximum Arresting Force (MAF) energy absorbing lanyards, properly rated full-body harnesses and connecting device
Accommodate single or multiple workers. Track allows workers to safely pass each other without disconnecting

Single Pole System

Space-saving design allows for installation in areas where there is minimal floor space or limited room for foundations
Utilizes only one free-standing support with one single foundation
Standard track lengths up to 53’
Systems are designed for workers up to 310lbs with tools when used with 900LB Maximum Arresting Force (MAF) energy absorbing lanyards, properly rated full-body harnesses and a connecting device
Track can accommodate single or multiple workers, dual bypassing track allows workers to safely pass each other without disconnecting
Special finishes available based on application requirements

Swing—Arm System

Provides circular or semicircular fall protection. Compact footprint
Versatile and adaptable. Swing arm can be positioned over the work space or moved out of the way when not in use
Wall-mounted, column-mounted or free-standing designs
Available in wall cantilever or wall bracket config., depending on headroom constraints
Infinitely variable friction brake or motorized rotation available
Standard arm lengths from 8’ to 30’, custom spans available upon request
Systems designed for workers up to 310lbs with tools. Standard design is to the latest lanyard standards of 900lb Maximum Average Arresting Force (MAAF) with a 1800lb Maximum Arresting Force (MAF)
Accommodates single or multiple workers, dual bypassing track allows workers to safely pass without disconnecting
